Dahua 4-Channel CCTV Power Supply 12V 2.5A Wall Mount (White) (PFM344D-4CH-EN)

  • Output: 4 Channels, 12V DC, 2.5A with 3-level voltage adjustment
  • Protection: Overcurrent, short-circuit, and 4 kV surge protection
  • Build: V-0 fireproof wall mount housing (Level VI efficiency)
  • Fast shipping to Latvia, as well as Estonia and Lithuania. 2-Year Warranty for all clients (Business & Private).

Dahua

15,29€
€12.64 (bez PVN)

> Outputs through 4 channels and can supply to multiple devices at the same time.
> The output voltage can be adjusted to 3 levels, making it easily adapt to various types of devices.
> Easy to install, the device supports wall mount installation.
> Designed with protection against overcurrent, overvoltage, and short circuits.
> Surge protection: common mode: ±4 kV, differentiate mode: ±2 kV.
> V-0 fireproof.
> CE certification.
> Efficiency Level: VI


Unit Box Height0.14
Unit Box Length0.14
Unit Box Width0.043
Shipping Box Width4.30000019073486cm
Shipping Box Depth14cm
Shipping Box Height14cm
Shipping Box Weight0.330000013113022kg
Units per Pallet0
Unit Calculated Volume0.0008428cubm
Units per Shipping Box1
Product Net Weight0.27kg
Unit Calculated Weight0.33kg
Dimensions140.1 mm × 94.5 mm × 34.2 mm
NamePOWER SUPPLY 12V 2.5A/PFM344D-4CH-EN DAHUA
SKU: DAHUA-PFM344D-4CH-EN Category:

Based on 0 reviews

0.0 overall
0
0
0
0
0

Only logged in customers who have purchased this product may leave a review.

There are no reviews yet.

What warranty and repair coverage is provided?

Apsardze24.lv provides a 2-year warranty for both private and corporate buyers. All technical inquiries and repairs are handled locally via our service center in Riga.

Is this power distribution unit certified for European installations?

Yes, this is an official EU-specification unit with CE certification and Level VI energy efficiency standards. It operates safely within standard European mains electrical installations.

How do I calculate if my cameras exceed the 2.5A rating of the Dahua PFM344D-4CH-EN?

Sum the maximum power consumption of all connected cameras, accounting for peak draw when infrared (IR) LEDs activate at night. If you need assistance verifying your system's load compatibility, contact our technical team at [email protected].

Does this power supply protect security cameras against electrical surges?

Yes, it features integrated surge protection of ±4 kV in common mode and ±2 kV in differential mode. It also includes short-circuit, overvoltage, and overcurrent protections housed in a V-0 flame-retardant casing.

Can the Dahua PFM344D-4CH-EN power 4 CCTV cameras simultaneously?

Yes, it provides 4 individual output channels with a combined total power output of 12V DC at 2.5A (30W). The current dynamically distributes across the channels, allowing you to run four standard CCTV cameras (drawing ~0.5A each) without issue.

What is the purpose of the 3-level voltage adjustment switch?

The 3-level adjustment allows you to compensate for DC voltage drop over long cable distances. Stepping up the output voltage ensures cameras installed far from the power unit still receive a stable 12V DC.
