FAL651FSP12 (Black) 85% Eff Tecnoware 650W Active PFC ATX Power Supply

Availability:

Out of stock Check availability

Availability:

Out of stock

  • Power: 650W / 85% Efficiency
  • Cooling: 120mm Silent Fan
  • Cables: Flat Connectors
  • Fast shipping to Latvia, Estonia, Lithuania. 2-Year Warranty.

TECNOWARE

37,57€
€31.05 (bez PVN)

Out of stock

650 W | 180 – 264 V | Efficiency 85 % | PC | ATX | Fan diameter 120 mm | Weight 1 kg

Internal power supply for personal computer, power 650W, input voltage 230 Vac, 50/60 Hz, conforms to ATX 12V v.2.31 specifications, main switch, surge protection, overload protection, short circuit protection, high MTBF, high reliability, quiet operation, 12 cm silent fan, temperature control of fan speed, Flat type connection cables from 500mm to 800mm, 1 x 20+4-pin connector, 1 x 12V 4+4-pin connector, 1 x 6+2 PCI-E connector, 2 x Molex connectors, 4 x Sata connector, dimensions 150x140x86 mm, weight 1.0 Kg, black color, CE certification, RoHS.

  • Internal Power Supply for Computers
  • High Efficiency (>85%) and High Operation Noise
  • Active PFC >0.9
  • Dimensions: 140x86x150 mm (WxHxD)
  • Input voltage 230 Vac 50Hz
  • Temperature control of the fan speed
  • Flat connection cables from 500mm to 800mm
  • Surge protection
  • Overload protection
  • Short circuit protection
SummaryTecnoware FAL651FSP12. Total power: 650 W, AC input voltage: 180 – 264 V, AC input frequency: 47 – 63 Hz. Motherboard power connector: 24-pin ATX. Purpose: PC, Power supply unit (PSU) form factor: ATX. Product colour: Black, Cooling type: Active, Fan diameter: 12 cm. Width: 150 mm, Depth: 140 mm, Height: 86 mm
Unit Box Height0.095
Unit Box Length0.22
Unit Box Width0.155
AC input frequency47 – 63Hz
AC input voltage180 – 264V
Efficiency85%
Max output current (+12V)26A
Max output current (+3.3V)25A
Max output current (+5V)26A
Max output current (+5Vsb)2.5A
Max output current (-12V)0.8A
Power Factor Correction (PFC) typeActive
Power protection featuresOverload/Short circuit/Surge protection
Total power650W
CPU power connector (4+4 pin)Yes
Motherboard power connector24-pin ATX
Number of SATA power connectors4
PCI Express power connectors (6+2 pin)1
Peripheral (Molex) power connectors (4-pin)2
80 PLUS certificationNo
ATX version2.31
Power supply unit (PSU) form factorATX
PurposePC
Cooling typeActive
Fan diameter120mm
Number of fans1fan(s)
On/off switchYes
Product colourBlack
Operating temperature (T-T)0 – 40°C
Storage temperature (T-T)-15 – 40°C
Depth140mm
Height86mm
Weight1000g
Width150mm
Units per Pallet0
Units per Shipping Box8
Unit Calculated Volume0.00405cubm
Unit Calculated Weight1.25kg
SKU: TECNOWARE-FAL651FSP12 Categories: ,

Based on 1 review

0.0 overall
1
0
0
0
0

Only logged in customers who have purchased this product may leave a review.

  1. Mark Thompson –

    Solid power supply for the price. The 650W output is steady, and I really appreciate the flat cables—they made building my PC much neater. The fan is quiet as advertised. Great service from the shop, everything arrived on time. Definitely recommend it.

    Mark Thompson –

Does the Tecnoware 650W power supply have built-in protection against power surges?

Yes, hardware safety is a priority at Apsardze24.lv. This power supply includes multiple layers of protection, including surge protection, overload protection, and short-circuit protection, to safeguard your expensive computer components from electrical faults.

Is the fan on this 650W Tecnoware power supply loud during heavy use?

The unit is optimized for quiet operation, featuring a 120mm silent fan. It utilizes intelligent temperature control to adjust the fan speed automatically based on the system load, ensuring the PC remains quiet during standard tasks and stays cool during heavier workloads.

Can I use the FAL651FSP12 to power a modern gaming graphics card?

This 650W unit includes one 6+2 pin PCI-E connector, making it suitable for many mid-range gaming graphics cards. For specific compatibility regarding the power draw of high-end GPUs, please contact our technical support at [email protected].

What are the benefits of the Active PFC in this power supply?

Active Power Factor Correction (PFC >0.9) improves power efficiency and reduces electrical harmonics. This leads to a more stable power delivery to your components and helps the unit achieve its 85% efficiency rating, ultimately saving energy compared to passive PFC units.

Will the FAL651FSP12 fit a standard micro-ATX or ATX motherboard?

Yes, it follows the standard ATX form factor (150x140x86 mm). It is equipped with a universal 20+4 pin motherboard connector and a 4+4 pin CPU connector, ensuring it is compatible with the vast majority of modern ATX, mATX, and Mini-ITX motherboards.

Is this FAL651FSP12 the official EU version for European power grids?

Yes, this is the official EU version specifically designed for 230 Vac (180-264V) input. As an authorized partner, Apsardze24.lv ensures these units are fully compliant with CE and RoHS safety certifications, meaning they are not region-locked and receive full support.

Are the cables on the FAL651FSP12 long enough for a large tower case?

Yes, the FAL651FSP12 is designed with flexibility in mind, featuring flat connection cables that range from 500mm to 800mm in length. This allows for clean cable management and easy routing even in larger ATX mid-tower chassis.

What happens if my FAL651FSP12 650W PSU fails after the first year?

We provide a comprehensive 2-year warranty for both private and business customers. Our local service center is located in Riga, which allows us to offer fast repairs or replacements without the hassle of shipping your product to another country.
