Dahua Vandal-Proof Access Reader with Keypad, Mifare 13.56MHz, Wiegand/RS-485 (DHI-ASR1101M-V1)

  • Modes: Mifare Card, Password, Combination
  • Build: IK08 Vandal-proof, Metal Keypad
  • Interface: RS-485, Wiegand 26/34
  • Features: Tamper Alarm, Backlight
  • Fast shipping to Latvia, as well as Estonia and Lithuania. 2-Year Warranty for all clients (Business & Private).

Dahua

67,34€
€55.65 (bez PVN)

Operating temperature range –10 °C to +55 °C | Power supply requirements 9–15 VDC, 100 mA

DHI-ASR1101M-V1 Vandal-proof Indoor Password IC Card Reader
> The metal keypad has a backlight and makes a beeping sound each time you press a key on it.
> High-performance 32-bit processor.
> 3 identity verification modes: Card, password, and a combination of card and password.
> Contactless card reading. Supports reading Mifare cards (IC card).
> Works at a frequency of 13.56 MHz.
> RS-485 and Wiegand communication.
> Highly compatible with third-party products, the device supports the W26 and W34 Wiegand interface, with W34 as the default.
> Provides online updates.
> Buzzer and indicator light.
> Lightning-proof, antistatic, and anti-short-circuit design.
> Built-in dongle software ensures long-term operation of the device.
> Tamper alarm.
> Overcurrent and overvoltage protection for all interfaces.
> IK08 rated.
> Operating temperature is –10 °C to +55 °C, and the operating humidity is less than 95%.
> Supports surface mount and flush mount (86 mount box is required).


Operating temperature range–10 °C to +55 °C
Power supply requirements9–15 VDC, 100 mA
Dimensions110 × 85 × 26 mm
Unit Calculated Volume0.00186cubm
Product Net Weight0.48kg
Unit Calculated Weight0.56kg
SKU: DAHUA-ASR1101M-V1 Category:

Based on 1 review

0.0 overall
1
0
0
0
0

Only logged in customers who have purchased this product may leave a review.

  1. Sarah Jenkins –

    The build quality is solid—feels properly vandal-proof with that metal casing. It’s working perfectly with our existing Mifare cards. Setup via Wiegand was straightforward. Delivery from apsardze24.lv was quick and hassle-free. Definitely recommend if you need a tough keypad reader.

    Sarah Jenkins –

Is the DHI-ASR1101M-V1 a standalone access controller?

No, this device is a slave access reader only. It does not control locks directly and must be connected to an access controller via RS-485 or Wiegand to function.

Does the keypad have backlighting for night use?

Yes, the metal keypad features a built-in blue backlight, allowing users to easily enter passwords or locate the card reader in low-light conditions.

Can I install the DHI-ASR1101M-V1 outdoors in winter conditions?

The operating temperature range is –10 °C to +55 °C, which is designed primarily for indoor or sheltered use. It is not suitable for extreme outdoor winter temperatures in the Baltic region.

What type of mounting box is required for flush installation?

While it supports surface mounting, flush mounting requires a standard 86-type installation box (switch box) which must be purchased separately.

The reader beeps but does not unlock the door, what should I check?

Ensure the reader is correctly wired to the controller and the user has valid permissions. If the problem continues, please contact our technical support at [email protected].

Does the package include a 12V power adapter?

No, a power supply is not included in the box. You will need to provide a separate 9–15 VDC power source or power it directly from your access controller.

How do I connect this reader to a third-party access controller?

You can use the Wiegand interface (supports W26 and W34 formats), which ensures compatibility with most non-Dahua access controllers.

What warranty coverage is provided for this Dahua reader?

Apsardze24.lv provides a full 2-Year Warranty for all clients (both business and private), with local service support based in Riga.

Which specific cards does this Dahua reader support?

This model supports 13.56 MHz Mifare (IC) cards. It is not compatible with 125 kHz EM proximity cards.

What does the IK08 rating mean for this keypad?

IK08 indicates the device is vandal-proof and protected against 5 joules of impact. The metal keypad design further ensures durability in public or high-traffic areas.
