Ajax LightCore (1-gang) 45110 Smart Switch Relay Mechanism (No Neutral Wire)

  • Component Type: 1-gang relay base for Ajax LightSwitch (Requires SoloButton).
  • Installation: Fits standard EU mounting boxes; no neutral wire needed.
  • Connectivity: Jeweller radio technology with up to 1,100 m range.
  • Power: Supports lamps from 5 W to 600 W.
  • Fast shipping to Latvia, as well as Estonia and Lithuania. 2-Year Warranty for all clients (Business & Private).

AJAX

53,24€
€44.00 (bez PVN)

Dimensions 76.3 × 72.3 × 29.2 mm | Product Net Weight 0.045 kg

LightSwitch combines the reliability of professional security systems and a thoughtful user experience. The smart switch from Ajax has a large touch-sensitive panel that can be activated both by tap and contactless – just put your hand less than 15 mm close. A soft backlight helps do this in the dark. With LightSwitch, it’s easy to turn on lights and floor lamps, control curtains or blinds, even remotely.
LightSwitch is easy to install: it is sized to fit into a standard European socket, does not require a neutral wire and connects to the security system by scanning a QR code. The settings in the app allow you to turn on the lights by schedule, when disarming the security system or in response to an alarm. The switch is available in eight colours, has one-gang, two-gang and two-way versions.
LightSwitch is a prefabricated smart light switch. All switch elements are purchased separately. Elements are connected mechanically without the use of tools. There are two LightSwitch formats in the Ajax product line: single and combined.
A single LightSwitch consists of two elements: a LightCore relay and a SoloButton touch-sensitive panel.
A combined switch consists of several LightCore relays and touch-sensitive panels installed in one frame with the appropriate number of seats.
The device is designed for indoor installation only. A professional electrician should install a device.

Unit Box Height0.08
Unit Box Length0.08
Unit Box Width0.035
Dimensions76.3 × 72.3 × 29.2 mm
Units per Shipping Box1
Unit Calculated Volume0.000224cubm
Product Net Weight0.045kg
Unit Calculated Weight0.067kg
SKU: AJAX-45110 Categories: ,
Brand

Based on 0 reviews

0.0 overall
0
0
0
0
0

Only logged in customers who have purchased this product may leave a review.

There are no reviews yet.

Can I connect the Ajax LightCore 45110 directly to Wi-Fi?

No, this device does not use Wi-Fi. It uses the proprietary **Jeweller radio protocol** to communicate with an Ajax Hub or Hub Plus. This ensures a long range (up to 1,100m) and stability, but it means you must have an Ajax security hub system installed.

What should I do if the device stops working after 12 months?

We provide a comprehensive **2-Year Warranty** for both business and private clients. If you experience issues, our service center is located locally in **Riga**, ensuring fast diagnostics and repairs without the need to ship the unit abroad.

Which mobile application is required to configure the Ajax LightCore 45110?

You need the **Ajax Security System** app, which is available for free on both iOS and Android. Through the app, you can pair the device, configure automation scenarios, and control your lighting remotely.

Does the Ajax LightCore 45110 require a neutral wire for installation?

No, this specific model (45110) is designed for homes with standard electrical wiring where no neutral wire is present in the mounting box. It operates on a single phase and controls lighting ranging from 5 W to 600 W.

Can I set the lights to turn off automatically when I arm my security system?

Yes. One of the main benefits of integrating the LightCore into the Ajax ecosystem is automation. You can create scenarios in the app to turn off all lights automatically when you arm the system or leave the house.

Is the cover panel included with this 1-gang relay mechanism?

No, the LightCore is only the internal relay mechanism. To have a fully functional switch, you must separately purchase the **SoloButton** (touch-sensitive panel), which is available in various colors to match your interior.

I have a complex multi-way switching setup; is this compatible?

This specific unit is a 1-gang relay. While Ajax offers 2-way versions, compatibility depends on your specific wiring diagram. If you are unsure about your wiring setup, please email our technical support at [email protected] for advice.

Is this the official European version of the Ajax LightCore?

Yes, this is the **Official EU version**. It is fully compatible with European electrical standards and receives all official firmware updates. As an Authorized Partner, Apsardze24.lv guarantees the device is not region-locked.

What happens if my light bulb is less than 5 Watts?

The operating range for this relay is 5 W to 600 W. If you connect a lamp with lower power consumption, it may flicker or not turn off completely. In such cases, a bypass capacitor might be required, or you should ensure the load meets the minimum specification.
